Socket holder with 4.5 and 5.5 mm pegs

Gives every socket in your set its own spot, so you stop digging through a drawer for the 10 mm. Sockets sit on pegs in three stepped rows, small at the front and big at the back, with the size printed beside each one. Change the size range or the number of rows to match your set.

1 part · 52 g · 149 × 67 × 33 mm

Orange tray with three stepped rows of pegs holding sockets, each size labelled
Loading the 3D view
Loading the 3D view
No adjustable sizes

Ask for the sizes you want to tweak, e.g. “make the width adjustable”.

Change it in the Studio

Parts

  • socket holder · PLA · Flat bottom on the bed, pegs up

    No supports needed

Print settings

Layer height
0.2 mm
Walls
3
Infill
15%
Supports
None

Good to know

  • The pegs are sized to each socket's across-flats size and tapered 6% toward the tip, so the fit is snug near the base. I haven't tested it on real sockets. Try the Peg looseness slider if they're too tight or loose.
  • A 20 mm peg assumes your sockets' hex openings are at least that deep. Shallow ones will sit on the peg tip; lower the Peg height slider if so.
  • The report still lists thin ledges. They are the flat bottoms of the engraved size numbers on the front step, and they are on purpose.
